UniFi Switch Ultra

Compact 8-port GbE PoE+ switch built for versatile wall, desktop, or ceiling mounting — ideal for AP deployments where the switch lives close to the access point.

The USW-Ultra packs 7 PoE+ output ports and 1 GbE uplink into a flush, low-profile housing with desktop and wall-mount options. PoE budget scales with the power supply used: PoE++ input provides 42W; optionally pair with the separately-sold USW-Ultra-60W or USW-Ultra-210W supply for expanded budgets. PSU not included.

Key Specs

• (7) GbE PoE+ ports + (1) GbE uplink; up to 30W per PoE+ port
• Total PoE budget: 42W (PoE++ input) up to 202W (with 210W PSU)
• 16 Gbps switching capacity, 8 Gbps non-blocking throughput
• Layer 2 managed; VLAN, 802.1X, LACP, storm control, IGMP snooping
• Silent, fanless; desktop, wall, or ceiling mount
• 8W max (excl. PoE); PSU sold separately
• NDAA compliant | FCC, CE, IC certified

What's in the Box

• USW-Ultra switch
• Mounting kit
• Quick Start Guide

Condition: New, factory sealed. Full manufacturer warranty. Requires UniFi Network 7.4+. Power supply (PSU) sold separately.
